JavaScript - Simple Remove Object By Dragging

Submitted by razormist on Friday, January 25, 2019 - 10:12.
In this tutorial we will create a using JavaScript. JavaScript is a scripting or programming language that allows you to implement complex things on web pages. It is widely used in designing a stunning website. It is an interpreted programming language that has a capabilities of Object-Oriented. So Let's do the coding...

Getting started:

This is the link for the bootstrap that i used for the layout design https://getbootstrap.com/.

The Main Interface

This code contains the interface of the application. To create this just write these block of code inside the text editor and save this as index.html.
  1. <!DOCTYPE html>
  2. <html lang="en">
  3. 	<head>
  4. 		<meta charset="UTF-8" name="viewport" content="width=device-width, initial-scale=1" />
  5. 		<link rel="stylesheet" type="text/css" href="css/bootstrap.css"/>
  6. 	</head>
  7. <body>
  8. 	<nav class="navbar navbar-default">
  9. 		<div class="container-fluid">
  10. 			<a class="navbar-brand" href="https://sourcecodester.com">Sourcecodester</a>
  11. 		</div>
  12. 	</nav>
  13. 	<div class="col-md-3"></div>
  14. 	<div class="col-md-6 well">
  15. 		<h3 class="text-primary">JavaScript - Simple Remove Object By Dragging</h3>
  16. 		<hr style="border-top:1px dotted #ccc;"/>
  17. 		<div style="background-color:#fff; border:1px dotted #000; height:150px;" ondrop="drop(event)" ondragover="dragOver(event)">
  18. 			<center><img src="image/trash.png" height="150" width="300"/></center>
  19. 		</div>
  20. 		<div style="margin-top:100px;">
  21. 			<img id="img1" src="image/img1.png" height="100" width="150" style="border:1px solid #000; float:left; margin-left:50px;" draggable="true" ondragstart="drag(event)"/>
  22. 			<img id="img2" src="image/img2.jpg" height="100" width="150" style="border:1px solid #000; float:left; margin-left:50px;" draggable="true" ondragstart="drag(event)"/>
  23. 			<img id="img3" src="image/img3.jpg" height="100" width="150" style="border:1px solid #000; float:left; margin-left:50px;" draggable="true" ondragstart="drag(event)"/>
  24. 		</div>
  25. 	</div>
  26. <script src="js/script.js"></script>
  27. </body>
  28. </html>

Creating the Script

This code contains the script of the application. This code will delete the draggable object when drop in the target zone. To do this just copy and write these block of codes as shown below inside the text editor and save it as script.js inside the js folder.
  1. function dragOver(e){
  2. 	e.preventDefault();
  3. }
  4.
  5. function drop(e){
  6. 	e.preventDefault();
  7. 	var data = e.dataTransfer.getData("data");
  8. 	var el = document.getElementById(data);
  9. 	el.parentNode.removeChild(el);
  10. }
  11.
  12. function drag(e){
  13. 	e.dataTransfer.setData("data", e.target.id);
  14. }
There you have it we successfully created a Simple Remove Object By Dragging using JavaScript. I hope that this simple tutorial help you to what you are looking for. For more updates and tutorials just kindly visit this site. Enjoy Coding!
